The Wood Pallet Shredder is engineered to efficiently process a variety of wooden and mixed-material pallets — including softwood pallets, hardwood pallets, and processed wood pallets — preparing them for reuse, recycling, or energy recovery.
The Genius Wood Pallet Shredder combines heavy-duty design, precise cutting, and operational efficiency to meet the demands of pallet recycling and wood waste processing.
Equipped with an STM high-precision gearbox from Italy for high torque density and accurate shaft movement, ensuring consistent performance with reduced energy costs.
Reinforced shaft and wear-resistant alloy steel blades maintain high cutting efficiency, even with continuous heavy-duty operation.
Modular knife system allows quick blade replacement to minimize downtime.
The integrated program monitors the shredding status in real time and automatically controls forward and reverse shaft rotation. This ensures stable operation, prevents material clogging, and maintains optimal throughput for consistent production efficiency.
Optional Equipment:
The Wood Pallet Shredder is engineered to efficiently process a variety of wooden and mixed-material pallets — including softwood pallets, hardwood pallets, and processed wood pallets — preparing them for reuse, recycling, or energy recovery.
The Genius Wood Pallet Shredder adopts a double-shaft shredding system as the standard configuration. Without a built-in screen, it delivers high throughput with lower risk of jamming — ideal for bulky pallets and mixed-material wood waste. While output particle size may vary, an optional screening system can be installed to achieve more uniform chip sizes.
Quickly shreds both softwood and hardwood pallets into uniform wood chips, ideal for biomass fuel or particleboard manufacturing.The double-shaft shredding system handles full-size pallets without pre-cutting, delivering high throughput and minimal risk of jamming. Standard configuration operates without a screen, resulting in varied chip sizes, while an optional screening unit can ensure more consistent output.
Designed to handle pallets made from processed wood materials such as plywood or chipboard, as well as pallets containing nails, screws, or metal brackets — no pre-sorting required.The double-shaft design easily tears through dense engineered wood and embedded metal components, maintaining blade integrity and throughput. Standard no-screen setup produces varied chip sizes, but an optional screening system is available for tighter size control.
The large feed opening accommodates bulky wooden crates, processed timber packaging, and other wood waste materials.The double-shaft system excels in processing oversized and irregular shapes, preventing blockages and reducing the need for pre-processing. While the standard no-screen configuration delivers variable chip sizes, an optional screening unit can be added for uniform particle size.
After processing with the Genius Wood Pallet Shredder, pallets are reduced to 30–100 mm wood chips (size adjustable by blade configuration).
Applications of Shredded Wood:
A: No. The machine can process pallets with nails or screws, and the magnetic separator will remove them during processing.
A: Yes. Output particle size can be adjusted by changing the screen size and cutting tool design, ranging from large pieces to fine chips.
A: With the STM gearbox and wear‑resistant blades, maintenance is minimal—mostly periodic lubrication and blade replacement.
A: It can be integrated with conveyor systems, magnetic separators, screening units, dust extraction, dryers, and composting lines.
A: Depending on the material and feeding method, the pre‑shredding stage can process several tons per hour, with stable throughput when integrated into a two‑stage shredding system.
A: Double-shaft shredders excel at processing bulky, irregular pallets without pre-cutting, offering high throughput. Single-shaft machines provide more uniform particle size but require pre-processing for oversized items. Our Wood Pallet Shredder comes standard as a double-shaft system with an optional screening unit for size control.
